1N5819

Manufacturer :

STMicroelectronics

Product Category :

Diodes - Rectifiers - Single

Package / Case :

DO-204AL, DO-41, Axial

Min Operating Temperature :

-65°C

Forward Voltage :

550mV

Voltage - Rated DC :

40V

Current Rating :

1A

Peak Reverse Current :

500μA

Current - Reverse Leakage @ Vr :

500μA @ 40V

Additional Feature :

FREE WHEELING DIODE

Terminal Form :

Wire

HTS Code :

8541.10.00.80

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Peak Non-Repetitive Surge Current :

25A

Diameter :

2.71mm

Lead Free :

Lead Free

Width :

2.7mm

Number of Elements :

1

Max Surge Current :

25A

Speed :

Fast Recovery =< 500ns, > 200mA (Io)

Weight :

4.535924g

Max Forward Surge Current (Ifsm) :

25A

Capacitance :

110pF

Max Reverse Leakage Current :

500μA

Voltage - Forward (Vf) (Max) @ If :

550mV @ 1A

Mount :

Through Hole

Base Part Number :

1N58

Packaging :

Tape and Box (TB)

Length :

5.2mm

Polarity :

Standard

REACH SVHC :

No SVHC

Max Operating Temperature :

150°C

Operating Temperature - Junction :

150°C Max

Forward Current :

1A

JESD-609 Code :

e3

Element Configuration :

Single

Number of Terminations :

2

Average Rectified Current :

1A

Factory Lead Time :

6 Weeks

Output Current :

1A

Pin Count :

2

Max Repetitive Reverse Voltage (Vrrm) :

40V

ECCN Code :

EAR99

Max Reverse Voltage (DC) :

40V

Diode Type :

Schottky

Mounting Type :

Through Hole

Radiation Hardening :

No

Diode Element Material :

SILICON

Number of Pins :

2

Contact Plating :

Tin

Height :

2.7mm

Case Connection :

Isolated

RoHS Status :

ROHS3 Compliant
